The multiple protection function of today s protection relay systems requires a new level of sophisticated test hardware and software to completely analyse the operation of the unit in a real life situation.
Megger 3 phase relay test set.
The built in user interface called the smart touch view interface is megger s second generation of automatic semi automatic manual user interface.
In addition various primary testing can be performed since the current and voltage sources can be series and or parallel connected to allow for up to 105 a ac or 900 v ac output.
With the voltage channels converted to currents the same unit can provide 6 phase current.
The sverker750 and sverker780 relay test set are the engineer s toolbox.
The engineer s toolbox for all single phase relay testing.
Lightweight rugged with high compliance voltage and test current.
The unit can be operated either manually via the built in touch screen user interface stvi or placed under full computer control via rtms relay test management software running on a pc.
The large display permits the user to easily read all pertinent data while the test is being performed and provides the ability to view the current transformer s saturation curve.
Megger s single phase relay test sets are essential items in the relay engineer s toolbox.
For full automatic testing the smrt1 may be controlled using relay test management software rtms.
Rtms is a microsoft windows xp service pack 3 vista 7 8 10 compatible software program designed to manage all aspects of protective relay testing using the new megger smrt.
The unit can also be configured to come without a megger stvi and can be controlled via a laptop with megger s powerdb software.
Rugged and reliable for field use.
The megger sverker 900 three phase relay test set is specifically designed for basic manual three phase secondary testing of protection devices.
Our aim is to make simpler the complex task of 3 phase relay testing.
The sverker 650 testing unit whose design incorporates benefits gleaned from many years of experience in field relay testing enjoys a well earned reputation for reliability and convenience.
A range of current and voltage channels options displays and added functions are all packed in to a powerful but light weight unit.
The smrt36 vigen modules also provide high power in both the voltage and current channels to test virtually all relays.
Our comprehensive and intuitive relay software speeds up testing times with a vast library of pre defined test regimes or manual operation.
Ideal for testing distribution networks industrial relays distance relays in rail power networks and many other applications.
Compact and powerful it provides all of the functions needed for secondary testing of almost all types of single phase protection now available on the.
